Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > ST187
Series No.： ST187
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 4.8mm[.187in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish | Wire Range | Thickness |
Packaging Quantity (Reel) |
Certified |
| ST1870302 | 0.3 | Brass | Tinned | 22-18 | 0.4 | 7 | - |
| ST1870303 | 0.3 | Steel | Ni-Plated | 22-18 | 0.4 | 7 | - |
| ST1870402 | 0.4 | Brass | Tinned | 22-18 | 0.36 | 7 | - |
| ST1870402-L | 0.4 | Brass | Tinned | 18-16 | 0.36 | 7 | - |
| ST1870403 | 0.4 | Steel | Ni-Plated | 22-18 | 0.4 | 7 | - |
| ST1870404 | 0.4 | Brass | Ni-Plated | 22-18 | 0.36 | 7 | - |
| ST1870410-L | 0.4 | Carbon steel | Tinned | 18-16 | 0.4 | 7 | - |
| ST1870501 | 0.5 | Brass | Unplated | 22-18 | 0.36 | 7 | - |
| ST1870501-L | 0.5 | Brass | Unplated | 18-16 | 0.36 | 7 | - |
| ST1870502 | 0.5 | Brass | Tinned | 22-18 | 0.36 | 7 | UL/CQC |
| ST1870502-L | 0.5 | Brass | Tinned | 18-16 | 0.36 | 7 | - |
| ST1870502-M | 0.5 | Brass | Tinned | 2X18 | 0.36 | 7 | - |
| ST1870502-S | 0.5 | Brass | Tinned | 24-20 | 0.36 | 7 | - |
| ST1870502-XL | 0.5 | Brass | Tinned | 2X16 | 0.36 | 5 | - |
| ST1870503 | 0.5 | Steel | Ni-Plated | 22-18 | 0.4 | 7 | UL/CQC |
| ST1870503-L | 0.5 | Steel | Ni-Plated | 18-16 | 0.4 | 7 | CQC |
| ST1870503-M | 0.5 | Steel | Ni-Plated | 2X18 | 0.4 | 7 | - |
| ST1870503-S | 0.5 | Steel | Ni-Plated | 24-20 | 0.4 | 7 | - |
| ST1870503-XL | 0.5 | Steel | Ni-Plated | 2X16 | 0.4 | 5 | - |
| ST1870504 | 0.5 | Brass | Ni-Plated | 22-18 | 0.36 | 7 | CQC |
| ST1870504-L | 0.5 | Brass | Ni-Plated | 18-16 | 0.36 | 7 | - |
| ST1870505 | 0.5 | Stainless Steel | Unplated | 22-18 | 0.4 | 7 | - |
| ST1870509 | 0.5 | Carbon steel | Ni-Plated | 22-18 | 0.4 | 7 | CQC |
| ST1870509-L | 0.5 | Carbon steel | Ni-Plated | 18-16 | 0.4 | 7 | CQC |
| ST1870510 | 0.5 | Carbon steel | Tinned | 22-18 | 0.4 | 7 | - |
| ST1870510-L | 0.5 | Carbon steel | Tinned | 18-16 | 0.4 | 7 | - |
| ST1870511 | 0.5 | Steel | Tinned | 22-18 | 0.4 | 7 | - |
| ST1870511-L | 0.5 | Steel | Tinned | 18-16 | 0.4 | 7 | - |
| ST1870602-M | 0.6 | Brass | Tinned | 2X18 | 0.36 | 7 | - |
| ST1870801 | 0.8 | Brass | Unplated | 22-18 | 0.36 | 7 | - |
| ST1870801-S | 0.8 | Brass | Unplated | 24-20 | 0.36 | 7 | - |
| ST1870802 | 0.8 | Brass | Tinned | 22-18 | 0.36 | 7 | CQC |
| ST1870802-L | 0.8 | Brass | Tinned | 18-16 | 0.36 | 7 | - |
| ST1870802-M | 0.8 | Brass | Tinned | 2X18 | 0.36 | 7 | - |
| ST1870802-S | 0.8 | Brass | Tinned | 24-20 | 0.36 | 7 | - |
| ST1870802-XL | 0.8 | Brass | Tinned | 2X16 | 0.36 | 5 | - |
| ST1870803 | 0.8 | Steel | Ni-Plated | 22-18 | 0.4 | 7 | CQC |
| ST1870803-L | 0.8 | Steel | Ni-Plated | 18-16 | 0.4 | 7 | CQC |
| ST1870803-M | 0.8 | Steel | Ni-Plated | 2X18 | 0.4 | 7 | - |
| ST1870803-S | 0.8 | Steel | Ni-Plated | 24-20 | 0.4 | 7 | - |
| ST1870803-XL | 0.8 | Steel | Ni-Plated | 2X16 | 0.4 | 5 | - |
| ST1870804 | 0.8 | Brass | Ni-Plated | 22-18 | 0.36 | 7 | CQC |
| ST1870804-L | 0.8 | Brass | Ni-Plated | 18-16 | 0.36 | 7 | - |
| ST1870805 | 0.8 | Stainless Steel | Unplated | 22-18 | 0.4 | 7 | - |
| ST1870807-S | 0.8 | Phosphor Bronze | Tinned | 24-20 | 0.36 | 7 | - |
| ST1870809 | 0.8 | Carbon steel | Ni-Plated | 22-18 | 0.4 | 7 | CQC |
| ST1870809-L | 0.8 | Carbon steel | Ni-Plated | 18-16 | 0.4 | 7 | CQC |
| ST1870810 | 0.8 | Carbon steel | Tinned | 22-18 | 0.4 | 7 | - |
| ST1870810-L | 0.8 | Carbon steel | Tinned | 18-16 | 0.4 | 7 | - |
| ST1870811 | 0.8 | Steel | Tinned | 22-18 | 0.4 | 7 | - |
| ST1870811-L | 0.8 | Steel | Tinned | 18-16 | 0.4 | 7 | - |
| ST1870812 | 0.8 | Stainless Steel | Unplated | 22-18 | 0.4 | 7 | - |
