Series No.： NR187187
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 4.8mm[.187in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > NR187
Series No.： NR187187
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 4.8mm[.187in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| NR1870502 | 0.5 | Brass | Tinned | 22-18 | 0.36 | 7K | UL |
| NR1870502-L | 0.5 | Brass | Tinned | 18-16 | 0.4 | 7K | UL |
| NR1870502-L-A | 0.5 | Brass | Tinned | 18-16 | 0.4 | 7K | - |
| NR1870509-L | 0.5 | Carbon steel | Ni-Plated | 18-16 | 0.4 | 7K | - |
| NR1870802 | 0.8 | Brass | Tinned | 22-18 | 0.36 | 7K | - |
| NR1870802-L | 0.8 | Brass | Tinned | 18-16 | 0.4 | 7K | UL |
