Series No.： NF187
Terminal Type： Receptacle
Terminal Orientation： Flag
Mating Tab width： 4.8mm[.187in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > NF187
Series No.： NF187
Terminal Type： Receptacle
Terminal Orientation： Flag
Mating Tab width： 4.8mm[.187in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| NF1870402 | 0.4 | Brass | Tinned | 22-18 | 0.4 | 5K | - |
| NF1870403 | 0.4 | Steel | Ni-Plated | 22-18 | 0.4 | 5K | - |
| NF1870501 | 0.5 | Brass | Unplated | 22-18 | 0.4 | 5K | - |
| NF1870502 | 0.5 | Brass | Tinned | 22-18 | 0.4 | 5K | UL/CQC |
| NF1870502-F | 0.5 | Brass | Tinned | 22-18 | 0.4 | 5K | - |
| NF1870503 | 0.5 | Steel | Ni-Plated | 22-18 | 0.4 | 5K | - |
| NF1870510 | 0.5 | Carbon steel | Tinned | 22-18 | 0.4 | 5K | - |
| NF1870510-XL | 0.5 | Carbon steel | Tinned | 2X18 | 0.4 | 5K | - |
| NF1870511 | 0.5 | Steel | Tinned | 22-18 | 0.4 | 5K | - |
| NF1870801 | 0.8 | Brass | Unplated | 22-18 | 0.4 | 5K | - |
| NF1870802 | 0.8 | Brass | Tinned | 22-18 | 0.4 | 5K | UL/CQC |
| NF1870803 | 0.8 | Steel | Ni-Plated | 22-18 | 0.4 | 5K | - |
| NF1870804 | 0.8 | Brass | Ni-Plated | 22-18 | 0.4 | 5K | - |
| NF1870804-F | 0.8 | Brass | Ni-Plated | 22-18 | 0.4 | 5K | - |
| NF1870804-XL | 0.8 | Brass | Ni-Plated | 2X18 | 0.4 | 5K | - |
| NF1870810 | 0.8 | Carbon steel | Tinned | 22-18 | 0.4 | 5K | - |
| NF1870811 | 0.8 | Steel | Tinned | 22-18 | 0.4 | 5K | - |
