Series No.: FT187
Terminal Type: Receptacle
Terminal Orientation: Flag
Mating Tab width: 4.8mm[.187in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > FT187
Series No.: FT187
Terminal Type: Receptacle
Terminal Orientation: Flag
Mating Tab width: 4.8mm[.187in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| FT1870302 | 0.3 | Brass | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870303 | 0.3 | Steel | Ni-Plated | 22-18 | 0.4 | 6K | - |
| FT1870402 | 0.4 | Brass | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870501 | 0.5 | Brass | Unplated | 22-18 | 0.4 | 6K | - |
| FT1870502 | 0.5 | Brass | Tinned | 22-18 | 0.4 | 6K | UL |
| FT1870502-F | 0.5 | Brass | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870502-L | 0.5 | Brass | Tinned | 18-16 | 0.4 | 6K | - |
| FT1870502-S | 0.5 | Brass | Tinned | 24-20 | 0.4 | 6K | - |
| FT1870502-XS | 0.5 | Brass | Tinned | 24-20 | 0.4 | 6K | - |
| FT1870503 | 0.5 | Steel | Ni-Plated | 22-18 | 0.4 | 6K | CQC |
| FT1870503-L | 0.5 | Steel | Ni-Plated | 18-16 | 0.4 | 6K | - |
| FT1870503-S | 0.5 | Steel | Ni-Plated | 24-20 | 0.4 | 6K | - |
| FT1870504 | 0.5 | Brass | Ni-Plated | 22-18 | 0.4 | 6K | - |
| FT1870504-L | 0.5 | Brass | Ni-Plated | 18-16 | 0.4 | 6K | - |
| FT1870511 | 0.5 | Steel | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870511-A | 0.5 | Steel | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870801 | 0.8 | Brass | Unplated | 22-18 | 0.4 | 6K | - |
| FT1870802 | 0.8 | Brass | Tinned | 22-18 | 0.4 | 6K | UL |
| FT1870802-F | 0.8 | Brass | Tinned | 22-18 | 0.4 | 6K | - |
| FT1870802-L | 0.8 | Brass | Tinned | 18-16 | 0.4 | 6K | - |
| FT1870803 | 0.8 | Steel | Ni-Plated | 22-18 | 0.4 | 6K | CQC |
| FT1870803-A | 0.8 | Steel | Ni-Plated | 22-18 | 0.4 | 6K | - |
| FT1870803-L | 0.8 | Steel | Ni-Plated | 18-16 | 0.4 | 6K | - |
| FT1870804 | 0.8 | Brass | Ni-Plated | 22-18 | 0.4 | 6K | - |
| FT1870804-L | 0.8 | Brass | Ni-Plated | 18-16 | 0.4 | 6K | - |
| FT1870811-F | 0.8 | Steel | Tinned | 22-18 | 0.4 | 6K | - |
| FT1872001 | 2 | Brass | Unplated | 22-18 | 0.4 | 6K | - |
| FT1872002 | 2 | Brass | Tinned | 22-18 | 0.4 | 6K | - |
